Started the build on a pair of Jack 112s with the 3012HO and melded piezo array. These will be for general use, but will spend most of their time in the small ballrooms of the event space featured in my T39 build thread. I went with the Jacks because they seemed the best fit for sub-less small PA with high efficiency. One of the "gigs" that these will be in is sitting on the bed cover of my pickup in a local parade in June. Not looking for main stage volume, but definitely want the music to be heard as we go by and I don't think the Jacks will have any issue delivering on that.
